130 152,4 mm

152,4 mm
110

67

Surface Mounted Concealed

Security Technical specifications
The ASSA ABLOY SW200i’s intelligent locking
features are designed for your peace of mind. For Power supply:
100-240 VAC +10/-15%, 50/60 Hz,
example, double doors are precisely controlled to mains fuse max 10A (building installation)
prevent jamming and increase security. The ASSA © All rights in and to this material are the sole property of ASSA ABLOY Entrance Systems AB. Copying, scanning, alterations or modifications are expressly forbidden without the prior written consent of the applicable company within ASSA ABLOY Entrance Systems AB.
ABLOY SW200i operator can also sense when the Power consumption: Max. 300 W
door has not closed completely and will prompt Auxiliary voltage: 24 V DC, max 700 mA
the door to open again and close fully, even under Ambient temperature: -20 °C to +45 °C
heavy wind load and stack pressure.
Recommended max. door weight
Aesthetics and door width:
The ASSA ABLOY SW200i swing door is providing Inertia J = Door Weight x (door width) 2
maximum performance with a capability to handle 3
heavy doors up to 320 kg. The ASSA ABLOY PUSH = 160 kgm 2
SW200i can be retrofitted with existing doors and PULL = 80 kgm 2
thereby keeping the overall door system design Concealed = 80 kgm 2
and environment aesthetically intact.
The SW200i complies with:
-EN 16005
The PUSH- and PULL system that is connected
to the output shaft, opens the door in a surface
mounted application. In a concealed application Accessories and Options 1010867-EI-1.0 – Issue 2013-05-20 – Rights reserved for changes without prior notice.
the output shaft is connected directly to the pivot Programme selectors
point.
Battery backup unit
Impulse and presence detection sensors
Fire kit
Arm systems PUSH, PULL and PAS

This equipment should be installed, regularly inspected, maintained and serviced by trained and authorized
personnel. Preventive maintenance plans are highly recommended for a proper and safe operation. Talk to
your ASSA ABLOY Entrance Systems representative to learn more about our service offering!

ASSA ABLOY Entrance Systems
Box 669, SE-261 25 Landskrona
Sweden
export.se.besam@assaabloy.com
Phone: +46 10 47 47 000
Fax: +46 418 212 50
www.besam.com

www.assaabloyentrance.com
