                             Security                                      Technical specifications
                             The ASSA ABLOY SW300’s intelligent locking
                             features are designed for your peace of mind. For   Power supply:
                             example, double doors are precisely controlled to   100-240 VAC +10/-15%, 50/60 Hz,
                             prevent jamming and increase security. The ASSA   mains fuse max 10A (building installation) © All rights in and to this material are the sole property of ASSA ABLOY Entrance Systems AB. Copying, scanning, alterations or modifications are expressly forbidden without the prior written consent of the applicable company within ASSA ABLOY Entrance Systems AB.
                             ABLOY SW300 operator can also sense when the   Power consumption:
                             door has not closed completely and will prompt   Max. 300 W
                             the door to open again and close fully, even under   Auxiliary voltage:
                             heavy wind load and stack pressure.           24 V DC, max. 700 mA
                                                                           Ambient temperature:
                             Aesthetics                                    -20 °C to +45 °C
                             The 70 mm slim ASSA ABLOY SW300 swing door    Recommended max. door weight
                             requires a minimum of space while providing   and door width:
                             maximum performance. Furthermore, the door    Inertia J = Door Weight x (door width) 2
                             system operates impressively silent despite its                  3
                             amazing capability to handle heavy doors up to             2
                             250kg. The ASSA ABLOY SW300 can be retrofitted   PUSH = 140 kgm
                             with existing doors and thereby keeping the   PULL = 80 kgm 2
                             overall door system design and environment    The SW300 complies with:
                             aesthetically intact.                         - EN 1154 (controlled door closing)
                                                                           - EN 1158 (coordination unit for rebated  doors)  1010468-EI-2.0 – Issue 2013-05-14 – Rights reserved for changes without prior notice.
                                                                           - DIN 18263-4
                                                                           - EN 1634-1
                                                                           - EN 16005
                                                                           - EN ISO 13849-1/-2
                                                                           - EN 60335-1
                                                                           - EN 60335-2-103
                                                                           - EN 61000-6-2
                                                                           - EN 61000-6-3

                             This equipment should be installed, regularly inspected, maintained and serviced by trained and authorized
                             personnel. Preventive maintenance plans are highly recommended for a proper and safe operation. Talk to
                             your ASSA ABLOY Entrance Systems representative to learn more about our service offering!
