COW
207

CL
Bi-parting
145 COW

CL
Left opening
COW

CL
Right opening

COW = Largeur de passage
CL = Longeur du capot

Design
The drive unit, control unit, transmission – or Standard equipment
optional emergency unit and electromechanical Support beam with transmission
locking device – are all assembled in the support Electronic control unit with plug-in connections and
beam. The drive unit transmits movement to the power supply
door leaves by means of tooth belts. The door Traffic-controlled opening width
leaves with integrated or separately mounted door
adaptors can be adjusted height-, length- and Synchronizing of two operators
depth-wise. Journalled steel rollers and sliding
tracks made of high-grade plastic give exceptionally
smooth and silent operation. Accessories and Options
Cover
Emergency - clear anodized aluminium
ASSA ABLOY UniSlide T can either be combined (other anodizing optional)
with a mechanical emergency unit that - paint finished in colour RAL 9010
automatically opens the doors–or an electronic (paint finishes according to RAL chart optional)
emergency unit that automatically opens or closes Door adaptor for doors up to 65 mm thickness made
the doors–in the event of a power failure. The by others
ASSA ABLOY UniSlide T can also be interfaced with Programme selectors
fire alarms or smoke detectors. Electronic emergency opening or closing unit
Mechanical emergency opening unit © ASSA ABLOY Entrance Systems AB - PD.UniSlide T/ORG.en-8.0/1803 - 1003751 Technical data subject to change without notice.
Models Break-out unit
ASSA ABLOY UniSlide T-2 – 4 leaves, bi-parting Emergency button
ASSA ABLOY UniSlide T-1 – 2 leaves, single slide,
right or left opening ASSA ABLOY approach and presence sensor
Presence detection photocells
Electromechanical locking devices
Interlocking between two operators
Key switch
ASSA ABLOY Automatic Door systems

This equipment should be installed, regularly inspected, maintained and serviced by trained and authorized personnel.
Preventive maintenance plans are highly recommended for a proper and safe operation. Talk to your ASSA ABLOY Entrance
Systems representative to learn more about our service offering!
